Pemko 157 Offset Saddle Threshold, 5 1/2" x 3/4"

Pemko 157 Offset Aluminum Threshold, 5 1/2" Deep x 3/4" Height
Pemko Fluted Offset Saddle Threshold 3/4in. x 5 1/2in.
Offset Saddle thresholds are commonly used to meet with an irregular floor surface.

Measuring 5-1/2" inches in width and 3/4" in height with a customized in length, the 157 Series Offset Saddle Threshold is designed to create a smooth transition between different floor surfaces, commonly used when meeting tile or carpet on one side. This aluminum threshold, with a fire-rated construction, is specifically crafted to accommodate a 1/2" height change in floor surfaces.

Technical:

• MATERIAL: 6063-T6 Aluminum Alloy
• WIDTH: 5-1/2” (139.7 mm)
• HEIGHT: 3/4” (19.1 mm)
• LENGTHS: 36″, 48″, 72″
• OFFSET:  Accommodates a Floor Condition with a 1/2" height change in floor surfaces.
• CERTIFICATIONS:
  • UL10C Positive Pressure
  • UL 4L10 Listed
  • ANSI/BHMA A156.21

Specs:

• Compliance/Ratings:  Fire Rated, BHMA Certified
• Size:  36", 48" 72" wide doors
• Usuage:  Interior or exterior openings
• Fasteners:  WS #10 x 1.5" included
• Filed Modification:  Can be field trimmed to meet your specific size
• Finish:
  • A - Mill Aluminum
  • D - Dark Bronze (Dark Brown)
  • BSP - Black Matte Powder Coat
• MDI Item #:  PEM-157__-
• Brand:  Pemko

* Door undercuts vary so be careful if this is being installed under a door.
