NGP 96V Series Aluminum Surface Door Sweep w/ Triple Fin Vinyl Seal

NGP 96V Series Aluminum Door Sweep w/ Triple Fin Vinyl Seal

Features of the NGP 96 Series Aluminum Door Sweep w/ Triple Fin Vinyl Seal

• Aluminum Alloy 6063, T5 Temper
• Thermo-Plastic Vulcanizate (TPV)
• Economical
• Flame-resistant
• Moisture-Resistant
• Temperature Range -40°F to 250°F
• #6 x 3/4" Stainless Steel SMS Furnished
• Screw Holes Slotted for Adjustment
• Vinyl is Black


 Certification:

• AIR INFILTRATION TESTED to ASTM E283:  Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.

• POSITIVE PRESSURE: CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.

• SMOKE & DRAFT CONTROL GASKETING: Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.

• ANSI Certified: UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.

• Available Finish:
  - 96V: Mill Aluminum w/ Black Neoprene Seal
  - 96VA: Anodized Aluminum w/ Black Neoprene Seal
  - 96VDKB: Dark Bronze Aluminum w/ Black Neoprene Seal

  Lead-Time:
  - Usually Ships within 3-5 business days
