Accentra (formerly Yale) 8805FL Storeroom Mortise Lock (F07), Lever Trim, US26D-Satin Chrome, For 1 3/4-inch Thick Doors
Accentra (formerly Yale) 8805FL Storeroom Mortise Lock (F07), Lever Trim, US26D-Satin Chrome, For 1 3/4-inch Thick Doors
SKU: SKU:YALE-AUR8805FL-626
Product Options:
Share
Accentra (formerly Yale) 8805FL Storeroom Mortise Lock (F07), Lever Trim, US26D-Satin Chrome, For 1 3/4-inch Thick Doors Information
Accentra 8805FL Storeroom Mortise Lock (F07)
ASSA ABLOY ACCENTRA™ 8800 Series Mortise Locks are designed and manufactured for uncompromising strength and durability in a range of commercial applications. Lock installation is made easy with quick lever handing, field reversible latchbolt and standard nonhanded strike. The 8800 Series Mortise Lock ANSI/BHMA Grade 1 certification for long life and durability.
Storeroom Function: For use on storeroom, utility, exit doors. Latchbolt retracted by key outside, knob/lever inside. Outside knob/lever rigid at all times. Inside knob/lever always active. Deadlocking latchbolt.
Product specs of the Accentra 8805FL Mortise Lock:
- ANSI/BHMA Code: A156.13
- ANSI/BHMA Series: Series 1000
- Backset Depth (Standard): 2 3/4"
- Cylinder: Optional
- Door Thickness (Standard): 1 3/4"
- Handing: Field Reversible
- Latchbolt Throw: 3/4"
- Maximum Backset: 2 3/4"
- Minimum Backset: 2 3/4"
- Maximum Door Thickness: 3 1/4"
- Minimum Door Thickness: 1 3/4"
- Number of Keys: 2 (when cylinder is ordered)
- Strike Type: Curved Lip
- UL Listed: Yes
- ULC Listed: Yes
-
UL Cycle above and beyond test completed at 12.3 Million
Cycles. Verification ID: V572228 - Warranty: 10-year (Mechanical)
Certifications:
- Environmental Product Declaration (EPD)
- CAL FIRE, 3775-0257:0113
- UL-cUL Fire-Rated Up to 3 Hours
- ANSI/BHMA A117.1
- ANSI/BHMA A156.13, Series 1000, Operational and Security Grade 1
-
Buy American Act*
*Domestic Sourcing regulations vary greatly within Federal, state and local government agencies and therefore certain restrictions may apply. Please contact BAACompliance.Americas@assaabloy.com for additional information.
