Material:
Brass, Stainless Steel
Available Finish:
US26D/626-Satin Chrome
Features:
3/4" Bolt Throw, 3/4" Rod Backset
12" Stainless Steel Rod Length (Center of Face to Bolt End- Retracted)
Standards:
Meets ANSI A156.16, L04251
UL Certified
Assembly Approved for Use in the State of Florida, Including the High Velocity Hurricane Zone (HVHZ)
Fire Rated up to and Including 3 Hours
Fasteners:
8 ea. #8 - 32 x 1/4" FH MS in Stainless Steel
Part Number |
Face Plate |
Mortise Body |
Rod Size |
Strike |
Guide |
Weight |
ANSI A156.16 |
| 556WS | 1" x 6-3/4" x 1/8" | 1" x 5-1/4" x 1-3/8" | 12" x 1/2" D | 15/16" x 2-1/4" | 1" x 2" | 2.5 lbs./2 | L04251 |
