Pemko CFS83HD1 Full Surface Continuous Hinge, 83-inch, Clear Anodized Alum.

Pemko CFS83HD1 Full Surface Continuous Hinge, 83"
The Pemko CFSHD1 Series Full Surface Continuous Geared Hinge is designed mainly for retrofit work and is applied to the exposed surfaces of the door and frame. This hinge is available in heavy duty models on thi spage, as well as our PemKonnect® modular version (FS_HD1-M) that is primarily designed for freight savings and ease of transportation via special order price quote.  Contact MDI for other models and a quote.

Fasteners:
Tek Screws (self-drilling) - included

Finish:
C - Clear Anodized Aluminum

Size & Handing:
83-inch: Non-Handed

Certifications:
Health Product Declaration (HPD)
UL 10C - Standard for Positive Pressure Fire Tests of Door Assemblies
ANSI/BHMA Standard A156.26

Features and Details:

• Bearing spacing: 3"
• Applied to the exposed surfaces of the door and frame
• Hollow metal door and frame manufacturers’ standard reinforcement is acceptable.
• Removal of hinge reinforcements in the door and frame is not advised.
• Special hinge reinforcements are not required.
• FirePins are required on 3-Hour (A-Label) assemblies
• Excessive clearance on fire rated assemblies may violate NFPA 80
• For swinging fire doors of hollow metal, tin-clad, sheet metal or steel covered composite type rated up to 3 hours.
• For wood covered composite type rated up to and including 1-1/2 hours.
• Guaranteed for the life of the opening against defects in material or workmanship (HD only)

SPECS:

• Grade: 1
• Hinge Material: Aluminum
• Hinge Strength: Heavy Duty
• Max Door Thickness: 1 3/4"
• Min Door Thickness: 1 3/4"
• Max Door Swing: 180°
• Minimum HInge Clearance: 1/16"
• Fasteners: Teks
• Fastener Type: Self-Drilling
• Max Door Wdith: 4'
