Hager Roton 780-053 Continuous Hinge - Half Surface
Hager Roton 780-053 Continuous Hinge - Half Surface
SKU: SKU:HAG-780-053-AL
Availability : Usually ships in 2-3 business days
Regular price
$159.50
Regular price
$291.50
Sale price
$159.50
Unit price
per
Shipping calculated at checkout.
Height: 8inch
Finish: Clear Alum.
Couldn't load pickup availability
Hager Roton 780-053 Continuous Hinge - Half Surface Information
HAGER ROTON 780-053 CONTINUOUS HINGE - HALF SURFACE
DOWNLOAD PRODUCT TEMPLATE HERE
| Clearance: | - | Refer to Door and Frame Dimensioning in the General Information section for further details |
| - | 5/32" (4 mm) minimum recommended hinge side | |
| - | Plus standard lockside clearance | |
| Fasteners: | - | Dril-Kwik (R) screws and Sex bolts |
| Length Options: | - | Standard and Custom |
| Door Reinforcement: | - | None required |
| Frame Reinforcement: | - | None required to 200 lbs. Heavier weight use 16-gauge channel. |
| Fire Rating: | - | Up to 3 hr. metal and 90 min. wood composite (with studs) |
| Special Features: | - | Security molding |
| - | Frame leaf alignment rib for proper hinge location | |
| - | 1/8" (3 mm) inset |
| Model | Length (inches) | Length (cm) | Hole Count (Door) | Hole Count (Jamb) |
| 780-053 | 79 | 200.7 | 8 | 15 |
| 780-053 | 83 | 210.8 | 8 | 19 |
| 780-053 | 85 | 215.9 | 8 | 19 |
| 780-053 | 95 | 241.3 | 9 | 19 |
| 780-053 | 119 | 302.3 | 10 | 21 |
