12" x 12" STC Sound Rated Steel Access Panel, STC-47, Powder Coat Prime Painted

Sound Proof STC Rated 47 Steel Access Panel for a Wall application only
This is the First true STC-Rated Access Panel on the Market!  Rated to STC 47 for Sound-Rated Walls to Help you Meet Noise Containment and Sound Transmission Blocking Requirements.

This is a Patent Pending product.

STC Rated Access Doors are custom manufactured, therefore orders cannot be canceled or returned.

»  Learning Spaces; LEED IEQ Enhanced Acoustical Perf. Credits for Schools / ANSI S12-60.
»  Healthcare; HIPAA Requirements for Patient Privacy
»  Judicial Setting; Meet GSA Acoustic Isolation Standards.
»  Group R Occupancies; Sound Isolation Between Units.

STC rated access panel technical data/feautres:
»  Construction: 16 gauge CRS 1” Wide Frame, and Door is 20 gauge CRS
»  Finish: Powder coat primer.
»  Hardware: Heavy Duty, Continuous Hinge
»  Latch/Lock: Compression Paddle Latch x Black Finish (Two at Heights Greater than 30”).
»  Gasketing: Heavy Duty EPDM Rubber
»  Insulation: Proprietary Sound-Blocking Assembly
»  STC (Sound Transmission Class) Rating: 47 When Installed as Directed in STC-rated Wall.
»  Sizes: Minimum 12” x 12”, Maximum 24” x 36”
»  Labeling: Intertek Warnock Hersey Listing

Special Quote Request Options:
»  Zinc-Plated Paddles Latches
»  Stainless Steel -16 ga Frame, 20 ga Door
»  Galvanneal Steel - 16 ga Frame, 20 ga Door
»  Other Powder Coat Paint Colors

...contact MDI Supply at 888.634.3667 to request a special quote on STC access doors with options.
